1. Easy access to double-sided empty tray

According to the targeted design of double-sided pallet, an integral manganese steel fork is formed. It is not necessary to add guide wheels to easily enter and exit the double-sided empty tray, so as to improve the work efficiency.

2. Battery side pull structure

The specially designed battery side pull structure composed of long-life bottom rollers can not only facilitate users to charge anytime and anywhere, but also replace the battery more conveniently and quickly.

3. Modular socket assembly

Maintenance is simpler and more intuitive

4. Comprehensive safety protection design

Control circuit and main circuit double circuit switch are adopted to ensure safe operation. In case of emergency, press the main circuit emergency stop switch to cut off all power supplies of the whole machine; An emergency reverse switch is added at the top of the operating handle (belly switch), when the operator encounters obstacles on the back of the vehicle, it can realize the emergency reverse function to prevent the operator from being hurt; the electromagnetic braking system can reduce the braking distance and realize the rapid braking function; the pallet stacker can also be equipped with protective arm, roof frame and other structures or lifting and deceleration functions to effectively protect the operator's safety.

5. AC drive motor + Curtis AC control system

AC AC drive motor can provide continuous and stable power, and can reflect superior power performance even under full load. AC Curtis 1230 controller has advanced heat dissipation system, compact design and fully enclosed interior, which can realize accurate control of the vehicle.

6. Electronic power steering system

Still worried about the constantly worn and peeling mechanical steering system connections? We provide a full-life electronic power steering system that requires little maintenance. Separate the steering system from the drive system to completely eliminate the disadvantages caused by the linkage steering of the drive system. The fault display function of the system can provide faster and simpler self diagnosis function. As for low energy consumption and noise, light operation experience and automatic reset protection function, it is even more common.

7. Floating force increasing mechanism of driving unit (automatic friction compensation of driving wheel)

The central booster cylinder is linked with the hydraulic system, and the pressure of the booster cylinder increases linearly with the increase of load, so as to linearly increase the friction coefficient of the driving wheel, ensure that the friction between the driving wheel and the ground is always in the best state, and completely solve the industry problem that the driving wheel is easy to slip under heavy load.
