Disc model

ZZ3167M3811,ZZ3167M3811

Drive model

4X2

cab

HW70 -- HOWO standard cab. The basic configuration is no sleeper and new seats; Up and down, front and rear adjustable steering wheel; European new integral air heater; VDO (Germany) instrument synchronized with the world's high-grade heavy trucks; road vehicles are four point full floating suspension (front coil spring, rear air spring) + damping device. Four point full floating spring suspension + damping device is used for off-road vehicles. Each type of cab is equipped with lateral stability device, double locking structure safety belt, external sunshade; fourth generation air conditioner. The air conditioner control panel is LCD display with LED lighting; cruise; generator voltage abnormal sound warning system (to prevent damage to electronic devices); electric doors and windows.

engine

Manufacturer: sinotruk

Diesel engine four stroke direct injection diesel engine

Engine model: WD615 62,  266HP ; WD615. 87,290HP

Emission standard: Euro 2

In line six cylinder water-cooled turbocharged intercooler

Displacement: 9.726 L

transmission case

HW19710, 10F & 2R, with PTO

steering system

ZF power steering model zf8118, power assisted hydraulic steering

the front axle

HF9,1x9000 KGS

Double section beam steering

rear axle

HC16, 1x16000 KGS

The pressure shaft housing, the central single reduction and the hub reduction, and the differential lock between the wheel and the axle.

Speed ratio: 4.8

chassis

Frame: there is a section of 300x80x8mm parallel ladder, and the cross beam reinforcement of subframe is cold riveted

Front suspension: 10 semi elliptical leaf springs, hydraulic telescopic double acting shock absorber and stabilizer

Rear suspension: 12 leaf semi elliptical spring, bogie spring and stabilizer

braking system

Braking: dual circuit pneumatic braking

Parking brake (emergency braking): spring energy, compressed air works on the front axle and rear wheel.

Auxiliary braking: engine exhaust braking

Power system

Working voltage: 24 V, negative grounding

Starter: 24 V, 5.4 kw

Generator: three phase, 28 V, 1500 W

Battery: 2 × 12V, 165ah

Cigarette lighter, horn, headlamp, fog lamp, brake lamp, indicator lamp and reversing lamp

tyre

11.00R20 with a spare wheel

tank

300L

Container

Length: 4.2m, 5.4m; Width: 2.3m; Height: 0.8-1.5m

vehicle size

7250*2550*3450mm
